1.scaling preventing
air skims over the surface of coils horizontally and spray water downward. water will not separated from coils caused by air flow so as to prevent forming scaling. coil heat conduction mainly depends on a significant way, compared to other conduction mainly depends on the latent heat (evaporation heat conduction) the way the structure of the scaling of even lower.
2.easy maintenance
large space design is convenient for maintenance even during operating situation, it’s available to check water and airflow status through access door.
3.low installation costs
modular design reduces installation and loading time for the lighter weight and the cost of supporting steel structure & pipes distribution can be greatly reduced.
4. flexible application
compact size, low noise & easy for placement sites.
optional components
all of the steel plate and structural items, including the structural framework, venetian support, the lower sink, fan platform and supporting can be optional type 304 stainless steel. the outer plates of cooling tower with two-sides inlet is made of frp,which is designed specially for longer service life.
1.electric heater
circulating water and spray water can freeze during cold winter months,which can bring out the disruption of pipes.we recommend electric heater and automatic control equipment to prevent fracture accident.if you need other antifreeze way you can contact with the company.
2.closed throttle (pcd) shields
positive closing throttle and throttle drive coil air intake guard can enhance the protective performance of heat loss.
3.electronic water level control package
when the water level control is required more in accurate or durable, it is widely used instead of water supply valve, including inductive devices and slowly closed solenoid valve.
4.lubricating tube extension
the end of lubricants tube is standard grease used to drive bearing lubrication, located near the maintenance room door.
5.tank cleaning piping
installed in water sink, it is used to remove the debris and bypassed connecting to the sand filtration equipment.
6.control device of bacteria, mucus and algae
precise dose and low concentrations of natural iodine is sprinklered into circulating water automatically to control bacteria, mucus and algae growth.
7.high temperature thermal sink
it is used in specific requirements when the fluid temperature of the cooler is high.
8.stand-alone fan system
each fan running individually can come true with dedicated motor and drive unit designed for cooler.
9.shock skip switch
two kinds of skip switch, with mechanical or electronic vibration functions can effectively prevent the equipment from breakdown due to excessive vibration of drive system.
10.external repair facilities
aluminum ladder, installation platforms, external door and motor platform are designed to facilitate the maintenance.
